Features:
1.High transmission efficiency, saving time and effort;
2.Adopt high-precision AC servo control, running smoothly and accurately;
Note:
1.The drive system adopts precision servo motor with adjustable speed;
2.The suction method can be vacuum suction cup or electromagnetic suction, and pneumatic clamps can be mixed to adapt to different workpieces;
3.Feeding method: coil material can be matched with air feeder, NC roller feeder; sheet material can be matched with double stacking rack;
4.If the workpiece needs to be reversed, it can be equipped with a reversing machine;
According to the requirements of the workpiece, it can be matched with an automatic tapping machine.
Technical Parameters
Model | Transfer Stroke | Lift Stroke | X/Y axis drive | Operation Screen | Operation Screen | Transfer Weight | Air Pressure | Customize Available |
ZBH-1500 | 800-1500mm | 10-60mm | Servo Motor | Color HMI | Vacuum/electro-magnet/SMART Clamp | 5KG/piece | >5KG | |
ZBH-2500 | 1600-2500mm | 10-60mm | Servo Motor | Color HMI | Vacuum/electro-magnet/SMART Clamp | 8KG/piec | >5KG | |
ZBH-3500 | 2600-3500mm | 10-60mm | Servo Motor | Color HMI | Vacuum/electro-magnet/SMART Clamp | 10KG/piece | >5KG | |
ZBH-5000 | 3600-5000mm | 10-60mm | Servo Motor | Color HMI | Vacuum/electro-magnet/SMART Clamp | 15KG/piece | >5KG |
